| Specification(example) |
(mm) |
| Length of Zirconia |
10.5 +/- 0.05 |
| OD D |
2.499 |
| OD Tolerance |
(S.M.)
(M.M.) |
|
+/- 0.0005
+/- 0.001 |
| Concentricity C |
(S.M.)
(M.M.) |
|
0.000 ~ 0.0014
0.000 ~ 0.005 |
|
|
0.125 ~ 0.126
0.127 ~ 0.128 |
| ID Tolerance |
(S.M.)
(M.M.) |
|
+0.001/ -0.000
+0.003/ -0.001 |
| Type of Flange |
4 slits |
| Material of Flange |
SUS303 |
|
|
