Performance Specifications
| Parameter |
Single |
Dual |
| Grade A |
Grade B |
Grade A |
Grade B |
| Central Wavelength (CW) |
1310 / 1550nm |
1310 / 1550nm |
| Minimum Spectral Bandwidth |
40nm |
40nm |
| Typical Insertion Loss |
0.15dB |
0.20dB |
0.20dB |
0.25dB |
| Maximum Insertion Loss |
0.20dB |
0.25dB |
0.25dB |
0.30dB |
| Minimum Return Loss |
65dB |
60dB |
60dB |
55dB |
| Maximum Acceptance Angle |
0.15 degree |
|
| Maximum Beam Diameter |
0.5mm |
|
| Maximum Optical Power |
300mW |
300mW |
| Maximum Tensile Load |
5N |
5N |
| Operating Temperature |
-20oC to +70oC |
-20oC to +70oC |
| Storage Temperature |
-40oC to +85oC |
-40oC to +85oC |
| Working Distance |
5, 10, 20mm or customers require |
|
|
|
