| Features |
- Rugged and small size
- Low Insertion Loss
- Environmentally stable and reliable
- Low polarization dependence loss
- Customer defined specification
|
| Applications |
- Telecommunications
- Local Area Networks(LAN)
- Optical Fiber Sensors
- Subscribe Loop
- Test Equipment
|
|
|
|
| Performance Specification |
| Item |
Optical Fiber Attenuator |
| Wavelength range |
850, 1310, 1550nm |
| Attenuation(dB) |
1 to 30 |
| Type |
In-line Type |
| Accuracy(Max., dB) |
+/-0.3(for 1 to 10), +/-0.5(for 10 to 30) |
| Return Loss(Min., dB) |
55 |
| PDL(dB) |
0.1 |
0.2 |
| Directivity(dB) |
55 |
| Temp. Coefficient(dB/oC) |
Typ. 0.002 |
| Operating Temperature |
-40 ~ 75oC |
| Storage environment |
-55 ~ 85oC |
| Pigtail length |
1m(or customer required) |
|
|
|
